1000万像素8mm 低畸变FA镜头C Mount

物距Working Distance

倍率 Optical Magnification

视野 2/3"Field of View(mm)

型号Model

HM0828MP10

mm

X

H

V

像机尺寸Image Size

2/3-inch

5000

0.002X

5371.8

4028.8

焦距Focal length

8mm

2000

0.004X

2156.4

1617.3

光圈范围F No.

F2.8-16

1000

0.008X

1084.6

813.5

最短物距M.O.D(m)

0.1-Inf.

900

0.009X

977.4

733.1

控制方式Operation

Iris

Manual手动调整

800

0.010X

870.3

652.7

Focus

Manual手动调整

700

0.012X

763.1

572.3

视场角

Angle of View

(D×H×V)

2/3"

67.6°×57.6°×44°

600

0.014X

655.9

491.9

1/2"

52.2°×42.8°×32.7°

550

0.015X

602.3

451.7

1/3"

40.3°×32.7°×24.7°

500

0.016X

548.7

411.5

畸变Distortion

<0.1%

450

0.018X

495.1

371.3

光学后焦BFL

11.5mm

400

0.020X

441.5

331.2

接口Mount

C-Mount

350

0.023X

387.9

291.0

近摄视野Object Dimension

227.2mm×170.4mm (WD=200mm)

300

0.027X

334.4

250.8

外形尺寸Dimension

Φ32×36.57mm

250

0.032X

280.8

210.6

重量Weight

63.5g

200

0.039X

227.2

170.4

滤镜尺寸Filter Thread

M30.5x 0.5

150

0.051X

173.6

130.2

工作温度Working Temperature

-20ºC ～ +60ºC

100

0.074X

120.0

90.0
