型号Model |
RV220MP5I |
CCD尺寸Image Size |
1/1.8-inch |
像圆Image Circle |
Φ5.4 |
光圈范围F No. |
F2.8-16 |
工作距离 WD (mm) |
5-70mm |
视场角Horizontal Angle of View |
178°×178°×178° |
分辨率Resolution |
10Mega Pixel |
波长范围Wavelength Range |
450-800 |
接口Mount |
C-Mount |
法兰后焦距Flange BFL |
17.526mm |
外形尺寸Dimension |
Ф17x64mm |
工作温度Working Temperature |
-20ºC ~ +60ºC |
